| Quantity: | |
|---|---|
刀插式2+4触点
YLS
刀插式2+4触点 | |
-40oC-+85oC | |
Rated Voltage | 500V AC |
Rated Current | 1-2 60A 3-6 5A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 800V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 67 |
Mechanical Life | 1000times |
Specification of used wire | 0.2mm-5.0mm |
Use | The Discharger End |
刀插式2+4触点 | |
-40oC-+85oC | |
Rated Voltage | 500V AC |
Rated Current | 1-2 60A 3-6 5A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 800V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 67 |
Mechanical Life | 1000times |
Specification of used wire | 0.2mm-5.0mm |
Use | The Discharger End |
