| Electrical properties | |
| Nominal voltage | 48V AC/DC |
| Rated current | 2A |
| Withstand voltage | 500V |
| Insulation resistance | ≤20mΩ |
| Contact resistance | ≤10mΩ |
| Mechanical property | |
| Inserting and removing force/inserting and removing mode | Insert force 80N Max, pull force 30N Min |
| Mechanical life | 200 times |
| Environmental resistance | |
| Operating temperature | -25℃~+80℃ |
| level of protection | IP66 |
| Wiring and appearance specifications | |
| The largest diameter | 13mm |
| Contact | Meet military standard copper alloy gold plating |
| Service wire specification | 0.14~0.34mm² |
