YLS-F-XZ3+5A20-8AT
YLS
YLS-F-XZ3+5A20-8AT | |
-40oC-+85oC | |
Rated Voltage | 500V AC |
Rated Current | 1-3 30A 4-6 3A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 8000V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 66 |
Mechanical Life | 1000times |
Specification of used wire | 0.2mm-3.0mm |
Use | Charger Cable |
