Charging and discharging integrated,We can also provide customization
| Quantity: | |
|---|---|
NL-Z2+4AT
YLS
NL-Z2+4AT | |
-40 °C-+85°C | |
Rated Voltage | 500 V AC |
Rated Current | 1-2 110A 4-6 5A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 1000V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 66 |
Mechanical Life | 1000times |
Specification of used wire | 0.5mm-6.0mm |
Use | Charging and discharging |
NL-Z2+4AT | |
-40 °C-+85°C | |
Rated Voltage | 500 V AC |
Rated Current | 1-2 110A 4-6 5A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 1000V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 66 |
Mechanical Life | 1000times |
Specification of used wire | 0.5mm-6.0mm |
Use | Charging and discharging |
