YLS-F-Z3+7AT
YLS
YLS-F-Z3+7AT | |
-30oC-+85oC | |
Rated Voltage | 500V AC |
Rated Current | 1-3 20A 4-10 3A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 500V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 66 |
Mechanical Life | 1000times |
Specification of used wire | 0.2mm-2.0mm |
Use | Motor Cable |
YLS-F-Z3+7AT | |
-30oC-+85oC | |
Rated Voltage | 500V AC |
Rated Current | 1-3 20A 4-10 3A |
Contact Resistance | ≤10 mΩ |
Insulation Resistance | ≥10 mΩ(under ordinary or in bumin environment) |
Withstand Voltage | AC 500V 50Hᶻ |
Material Of Contact | Gold-plated copper alloy |
Protection Degree | IP 66 |
Mechanical Life | 1000times |
Specification of used wire | 0.2mm-2.0mm |
Use | Motor Cable |
