YLS-F-L911AT
YLS
Product parameters | Signal Cable : YLS-F-L911AT |
Operating Environment | -30℃-+85℃ |
Rated Voltage | 500V AC |
Rated Current | 10A-20A |
Contact Resistance | ≤10mΩ |
Insulation Resistance | ≥10mΩ(Under ordinary or in bumin environment) |
Withstand Voltage | AC 500V 50HZ |
Contact Material | Gold-plated copper alloy |
Level of Protection | IPX6 |
Mechanical life | 5000 times |
Specification of used wire | 1.5mm |
Use | Motor lines |
Product parameters | Signal Cable : YLS-F-L911AT |
Operating Environment | -30℃-+85℃ |
Rated Voltage | 500V AC |
Rated Current | 10A-20A |
Contact Resistance | ≤10mΩ |
Insulation Resistance | ≥10mΩ(Under ordinary or in bumin environment) |
Withstand Voltage | AC 500V 50HZ |
Contact Material | Gold-plated copper alloy |
Level of Protection | IPX6 |
Mechanical life | 5000 times |
Specification of used wire | 1.5mm |
Use | Motor lines |
