YLS-F-L918AT
YLS
Product parameters | Motor Cable : YLS-F-L918AT |
Operating Environment | -40℃-+85℃ |
Rated Voltage | 500V AC |
Rated Current | 20A-40A |
Contact Resistance | ≤10mΩ |
Insulation Resistance | ≥10mΩ(Under ordinary or in bumin environment) |
Withstand Voltage | AC 800V 50HZ |
Contact Material | Gold-plated copper alloy |
Level of Protection | IPX7 |
Mechanical life | 5000 times |
Specification of used wire | 3.0mm |
Use | Motor lines |
